ELC-TM30N (Thru-Beam/30m/NPN)

Model

ELC-TM30N

Product

Laser Sensor

Model

Thru-Beam

Sensing Distance

30m

Output Type

NPN

Switch Action

Dark.ON&Light.ON

Model	ELC-TM30N
Sensing method	Through-beam
Sensing distance	30m
Spot size	φ30mm/30m
Output Type	NPN Open collector,≤100mA/30V DC
Switch Mode	L.on ( Light.ON )/D.on ( Dark.ON ) Selectable output types
Indicator	Ouptut Indicator: Orange； Laser Indicator: green
Response Time	0.25 ms
Sensitivity setting	Single-turn Potentiometer
Emitting Light	Laser (650nm )
Laser class	Class1
Operating Voltage	12~24V DC±10%
Current Consumption	＜30mA
Operating Temperature	-10℃~+50℃, No freezing
Operating Humid	35%~85%RH , No freezing
storage Temperature	-25℃~+70℃, No freezing
storage Humid	35%~95%RH , No freezing
Shock resistance	50G(500m/s²),XYZ each direction
Vibration resistance	10~55Hz amplitude 1.5mm，XYZ， 2 hours
Protection Degree	IP 67
Wiring Method	Emitter：2M 2-wires cable / Receiver：2M 3-wires cable
