ELS-ZL10P (Diffuse/10cm/PNP)

Model

ELS-ZL10P

Product

BGS Laser Sensor

Model

Diffuse Reflective

Sensing Distance

10cm

Output Type

PNP

Switch Action

Dark.ON&Light.ON

Category: Defaut

Model	ELS-ZL10P
Sensing method	Reflective-BGS
Setting sn	20~100mm
Sensing distance	5~100mm
Spot size	φ1mm/100m
Output Type	PNP Open collector,≤100mA/30V DC
Switch Mode	L.on ( Light.ON )/D.on ( Dark.ON ) Selectable output types
Indicator	Ouptut Indicator: Orange； Laser Indicator: green
Response Time	0.3 ms
Sensitivity setting	4-turn Potentiometer
Switch hysteresis	3%
Emitting Light	Laser (650nm )
Laser class	Class1
Operating Voltage	10~30V DC±10%
Current Consumption	＜30mA
Operating Temperature	-10℃~+50℃, No freezing
Operating Humid	35%~85%RH , No freezing
storage Temperature	-25℃~+70℃, No freezing
storage Humid	35%~95%RH , No freezing
Shock resistance	50G(500m/s²),XYZ each direction
Vibration resistance	10~55Hz amplitude 1.5mm，XYZ， 2 hours
Protection Degree	IP 67
Wiring Method	2M 4-wires cable
